〉Industrial Grade L2+ Managed PoE Switch
〉Industrial L2+ 8 x GE PoE + 4xGE SFP Managed PoE Switch
• Managing IP Surveillance
• Surge Protection 6KV
• -40°C ~ 75°C

Model: SW_01

Category: Networking Equipment

Tag: PoE Network Power Supply Device, Managed PoE Switch, Networking Switch, Power over Ethernet (PoE) Network Power Supply Equipment

The Root VivoCam Will Auto-Sync With All VivoCam Sub Switches
Auto Discovery and Classification of Network Devices
Batch Camera Configuration - File Import & Export
Batch Camera Network/Login Configuration
Auto Generated Surveillance Topology View
Easy Tag VLAN Configuration in Topology View
Smart Device-Management in Topology View
PoE On/Off Control in Topology View
Display IP Camera Live Stream in Topology View, Floor View and Google Map View
Supports Discovery of ONVIF IP Cameras

Console Port 10M/100M/1G RJ45 PoE Port 100M/1G SFP Port Switching Capacity Forwarding Capacity MAC Address Jumbo Frames Number of PoE Out Ports Max. PoE Output Power /Per Port Total PoE Power Budget
RJ45x1 8 4 24 Gbps 17.856 Mpps 8K 9600 Bytes 8 30W 240W
Power Pin Assignment Spanning Tree 802.1Q Tag-based VLAN Trunking:IEEE 802.3ad LACP Rapid Ring:Total Number of Switch Hardware Queues Operating Temperature Dimensions Weight
1/2(+), 3/6(-) IEEE802.1D (STP)/IEEE802.1w (RSTP) /IEEE802.1s (MSTP) 4096 VLAN IDs Up to 4 ports in a group, Max. up to 6 groups Up to 250 units 8 -40°C ~ 75°C (-40°F ~ 167°F) 62(W) x 135(H) x 130(D) mm 0.68 kg
  • Related Downloads
    Catalog Download on May, 2023
